Rough Terrain Stacker Manufacturer | Custom Outdoor Electric Stacker

Slippage on muddy, gravel outdoor yards brings huge safety hazards for stacking operations. Standard electric stackers fitted with PU wheels and low ground clearance often suffer low efficiency and safety risks. As a professional Rough Terrain Stacker Manufacturer, Newnewton provides customized rough terrain electric stackers tailored for outdoor harsh conditions.

Different from ordinary indoor warehouse stackers, our rough terrain models are fully upgraded against slippery ground pain points, with all parameters verified through 10,000-cycle fatigue testing in our factory. Test data is available for on-site inspection:

370×100mm deep-tread solid rough terrain tires, 32% higher grip Standard indoor PU tires feature shallow treads and smooth surfaces with weak friction on muddy ground. Newnewton equips thick deep-groove rubber tires with puncture & wear resistance. Full 1.5-ton load test on post-rain mud ground shows zero side slip; tire damage rate drops by 80% on gravel roads.

100mm raised ground clearance chassis to avoid chassis scraping & wheel jamming Conventional stackers only have 50mm ground clearance, easily scratching frames or trapping outriggers on potholes and stones. Our rough terrain version lifts the chassis to 100mm, freely passing dirt ruts and loading ramps to eliminate slipping risks fundamentally.

1.5kW travel motor + 2.2kW lifting dual motors, stable climbing on 15% gradient without rollback Ordinary warehouse stackers only support 6%-8% full-load climbing, lacking power and prone to backward sliding when starting on slopes. Newnewton high-torque brushless motors deliver 40% extra torque, matched with electromagnetic parking brake. Wheels lock automatically on 15° slopes without cargo sliding after releasing the handle, completely solving slope slipping hazards.

As a physical factory focusing on material handling equipment, Newnewton supports full customization of rough terrain stackers for all outdoor special working conditions:

Load customization: Standard 1.5-ton & 2-ton models, customizable 1-ton light-duty / 2.5-ton heavy-duty rough terrain stackers

Mast height customization: 2–3m two-stage mast, 3.5–4.5m triple full-free mast for outdoor high rack stacking

Body dimension customization: Narrow chassis, widened outriggers, shortened overall length for narrow outdoor ramps & greenhouse aisles

Battery customization: Standard lead-acid batteries, long-cycle lithium iron phosphate batteries for 8-hour two-shift continuous outdoor operation

Special working condition refits: Dustproof for construction sites, mud-proof for farms, low-temperature cold storage, narrow ramp dedicated schemes

Newnewton Electric Stacker boasts stable quality and complete service with CE & ISO certifications. Factory visits, machine test runs and free custom design services are available. All units come with a 1-year warranty to deliver reliable procurement experience for warehouse operators.
