3 Key Parameters To Select Narrow Aisle Double Pallet Truck For Dense Warehouse

Many high-density warehouses hope to boost handling efficiency by moving two pallets in one trip, yet they overlook the limitation of aisle dimensions. After purchasing double pallet trucks, operators find the vehicle stuck while turning, which brings unnecessary procurement loss. When selecting a narrow aisle double pallet truck, focus on these three core parameters to avoid most selection mistakes.

The first parameter is the minimum turning radius, a vital index for narrow aisle applications. Standard double pallet models feature a larger turning radius and suit spacious storage areas. The narrow aisle version adopts a shorter body and optimized steering structure to achieve a smaller turning radius. Calculate with the clear aisle width and reserve safety clearance, so the loaded vehicle with two pallets can complete turning without scratching racks and pallets.

The second parameter is rated load capacity and load center. Different from standard pallet jacks, an electric double pallet truck carries two pallets at the same time. Its load capacity cannot be simply calculated by adding the load of single pallet. Confirm the marked rated load for dual pallets and check the load center distance. Uneven pallet sizes and offset cargo gravity may lead to unstable travel and poor lifting performance. A proper load margin is recommended for high-frequency operations.

The third parameter is overall vehicle width and fork spread. The overall width determines the minimum accessible aisle, while fork spread needs to match regular pallet sizes, including standard EU pallets, standard domestic pallets or custom pallets. If goods extend outside pallets, calculate the total outer width of forks in advance to prevent collision during turning.

After confirming these parameters of the electric double pallet truck, you can further evaluate floor conditions, battery endurance and lithium battery options. Custom solutions for double pallet trucks are available for high-turnover dense storage. Share your warehouse working conditions and get our professional proposal.
