How Much Does a Double Pallet Stacker Cost? 3 Key Configuration Factors

Many enterprises inquire about double pallet stacker price, yet market quotations vary widely, making true‑to‑life comparison difficult. As high‑efficiency equipment handling two pallets per trip, the electric double pallet stacker fits e‑commerce warehouses, raw‑material storage and assembly‑line workshops. Below we cover price references and three core configurations that drive quotation differences.

Price reference range(converted by exchange rate 1CNY≈0.1482USD):

1.5‑ton standard lead‑acid model factory price: $5632‑$7114

Same‑spec lithium‑ion upgraded version: $6669‑$8596

Triple‑mast high‑lift & custom chassis models: $8892‑$11856. Imported brands of same specs generally cost 20‑30% more.

Configuration 1: Battery type and capacity, accounting for over 20% of total machine cost Lead‑acid battery is the entry‑level standard, suitable for single‑shift operation within 8 hours with low procurement cost. Its drawbacks are regular watering maintenance and 500‑800 charge‑discharge cycles. Lithium‑iron‑phosphate version is maintenance‑free and supports fast charging with over 2000 cycles, ideal for high‑frequency two‑shift work. Upgrading to lithium battery adds $593‑$1037 to machine cost. Many low‑cost quotations adopt small‑capacity batteries. Though seemingly cheap, they suffer insufficient continuous‑operation runtime and frequent charging downtime, hurting warehouse throughput. When comparing bids, always check battery Ah rating instead of merely noticing “lithium battery” label.

Configuration 2: Mast type and actual lifting height Mast steel thickness, hydraulic cylinders and chain specifications directly decide machine weight and load‑capacity attenuation. Two‑stage masts serve racks under 3 m. For racks over 3.5 m height, choose triple full‑free mast. Each extra 1 m lifting height pushes procurement cost up by 10‑15%. Pay attention to manufacturer‑stated maximum lifting height. Load capacity will drop at high lift. For instance, a 1.5‑ton unit loses partial residual capacity when lifting to 4.5 m. Request load‑curve data during procurement to avoid insufficient lifting power under full load.

Configuration 3: Load capacity and custom chassis‑forks The mainstream 1.5‑ton specification delivers cost‑effective performance for most double‑pallet warehouses. The heavy‑duty 2‑ton version reinforces motor, hydraulic power unit and frame steel plate, costing $889‑$1482 higher than the 1.5‑ton model. Besides, fork length and outer span of electric double pallet stacker need matching local pallet dimensions.

Minor details also influence pricing but create limited price gaps. If you need an exact quotation for double pallet stacker price, share your warehouse aisle width, required lifting height and load capacity, and we will match suitable models for you.
